Superfine Pre-alloyed Powder

Superfine Pre-alloyed Powder: KIN-04B

Superfine iron - copper - tin pre-alloyed powder, D50 is 12.0-18.0 microns. With high chemical activity, good cold press formability and good self-sharpening performance.

product details

Application

It can be used as formula powder for wet cut ceramics and sintered stone, or mixed with a small amount of reinforcing materials to perforate glass plate.

The Min. Sintering Temperature: 700℃

The Best Sintering Range: 720-750℃ (350kgf/cm²)

Data

Grade	Composition	Particle Size D50(μm)	Hardness (HRB)	Bending Strength (MPa)	Apparent Density (g/cm³)	Theoretical Density (g/cm³)
KIN-04B	Fe Cu Sn	12.0-18.0	95-105	680-750	1.3-1.9	8.0

Related products

Grade	Composition	Particle Size D50(μm)	Hardness (HRB)	Bending Strength (MPa)	Apparent Density (g/cm³)	Theoretical Density (g/cm³)
SCF-07	Fe Cu Sn	4.5-8.0	95-110	600-850	1.4-2.4	8.06
SCF-10	Fe Cu Sn P	24.76	95-105	1150-1250	1.5-1.8	8.08
KIN-04E	Fe Cu Sn Zn	8.0-16.0	100-105	600-750	1.5-2.1	8.01

The above product data and application suggestions may change due to product optimization, performance improvement, and other reasons. The current content is for reference only. Please contact us for the latest data.
